Force Measurement System
Strip-Tension / Web-Tension Meter
Strip-Tension / Web-Tension Meter
IMS force measuring systems measure strip tension continuously and in real time.
Strain-gauge based force transducers are mounted underneath the bearing housings to measure the reaction force as a function of the wrap angle of the measuring roll.
Optional wrap angle compensation is available for use of a strip tension measuring system to control strip tension during coil winding.
measurement of the horizontal or vertical force
calculation of the strip tension in dependence on the wrap angle
Special Features
- maintenance and wear free
- long service life
- small, compact and customised
- high dynamics and fast reaction to load changes
- high measuring accuracy and stability
- designed for up to 20-fold overload
- installation in virtually any environment due to hermetically sealed measuring body
- all common standard interfaces available
- sensors from other manufacturers can be adapted
- easy installation and commissioning due to the integrated calibration system and the electronic data sheet (EDS)
Reserve your personal consultation appointment now!
Choose between a scheduled call back, a Teams video conference or simply use our contact form.
We look forward to hearing from you!
Force Measurement System
Strip-Tension / Web-Tension Meter
Strip-Tension / Web-Tension Meter
Technical Information
Force Transducer HMK / VMK
Nominal sensitivity:
0.5 mV/V
Non – Repeatability / – Linearity:
≤ 0.05 % / ≤ 0.2 %
Zero drift:
≤ 50 ppm / °C
Limit – / Breaking – load:
800 % / 1,200 %
Operating temperature / Protection class:
-10 ..+80 °C / IP67
EDS (Electronic Data Sheet):
yes
Measuring Amplifier MMV
Input channels:
2 optionally 4
Permitted bridge resistance:
≥ 175 Ω
Excitation voltage / Measuring range per channel:
0..15 VDC / ± 0.125..2 mV/V (programmable)
Resolution A/D (input) – / D/A (output) converter:
± 32,767 digit
Sampling rate per channel:
up to 1,000 per second
Length of transducer cable:
≤ 30 m
Operating temperature / Protection class:
-10 ..+60 °C / IP65
EDS (Electronic Data Sheet) Function:
yes
Wide range of fieldbus modules available:
EtherCat, Profibus-DP, Profinet, Ethernet I/P (others on request)
Analog outputs:
2 (current ± 20 mA or voltage ± 10 V)
Digital in- / output:
each 4
Operating voltage (mains voltage):
24 VDC (0,2 A)
optionally 85-264 VAC 50-60 Hz (0,8 A)
